FETACA®OBD 2G Plug & Play GPS Tracker with Diagnosis for Car, Truck, Bus | (2G OBD)
OBD GPS Tracker with 2G Network Coverage for Cars, Buses, Trucks.
Features – Geo-fence, Vehicle Diagnosis, Over Speed Alert, Tamper Alarm, Live Tracking, Driving Behaviour Monitoring, OBD II Protocol, GPS+LBS Positioning, Low Power Protection, Plug and Play Device, Built-in Battery, Vibration Alarm, Collision Alarm, and Many More.
Accuracy – 10 Meters
Supported SIM Network – 2G
1 Year Software + 1 Year M2M Sim (No Voice Call)
FETACA®OBD 2G Plug & Play GPS Tracker with Diagnosis for Car, Truck, Bus | (2G OBD)
|
OBD With Diagnose 2G Specifications |
|
| Size | 48mm*25m*23mm (without plug) |
| Working Voltage | DC 9V~36V |
| Working Current | 35mA（ACC ON） |
| Standby Current | 2.5m（ACC OFF） |
| Backup Battery | 50mA polymer lithium battery |
| Positioning method | GPS/AGPS/LBS |
| Positioning accuracy | 10m |
| Communication Network | GPRS GSM850/900MHz/DCS1800MHz/1900MHz |
| Working Temp range | -25~+75℃ |
| Storage Temp range | -40~+85℃ |
| Function | Description | |
| Positioning & Tracking | The terminal detects the car ignition ACC ON, starts continuous positioning, and uploads the position data every 15s. When ACC OFF is detected and the position data is uploaded every 5 minutes (the last ACC ON GPS positioning data is retained). |
|
| Sleep & Wake-up Model | When ACC OFF, the equipment can be configured to sleep (GSM standby disconnected network connection) and wake up report position regularly. | |
| LBS/GPS Positioning | The device uses GPS positioning after power-on by default. If the GPS positioning is not successful, a group of base station data will be reported. | |
| Read VIN | Within 30 seconds after ACC ON, the device will actively read the vehicle identification number of the vehicle. |
|
| Read Diagnostic data | After the vehicle is started, the vehicle engine speed, vehicle speed, battery voltage, throttle opening, engine load, coolant temperature, intake airflow, intake air temperature, ignition advance angle, instantaneous fuel consumption, Average fuel consumption, current mileage, current fuel consumption, cumulative fuel consumption fault code, real-time data flow |
|
| Low power protection | detects that the vehicle voltage is too low, it will automatically enter the network, low power mode, default 11v |
|
| SMS setting | You can set the IP (or domain name), port number, APN, local number, working mode, etc. |
|
| Power cut alarm | When the external power supply is cut off, the power cut alarm will be reported. |
|
| Low power alarm | When the vehicle power supply is detected to be low, an alarm will be reported. The default is 11V. | |
| Vibration alarm | ACC OFF status, when the vehicle vibration is detected, the vibration alarm will be reported. | |
| Collision alarm | When the vehicle has a crash | |
| Speed alarm | When the vehicle speeding，default 120km/h | |
| Driving behavior monitoring | Statistical travel acceleration, rapid deceleration |
The FETACA® 2G OBD Plug & Play GPS Tracker is a compact, intelligent tracking solution designed for cars, trucks, and buses. It offers real-time GPS and LBS positioning to ensure accurate vehicle tracking even in low-signal areas. Once the vehicle ignition (ACC) is turned on, the device begins continuous positioning every 15 seconds; when the ignition is off, it switches to a power-saving mode and updates every 5 minutes.
This tracker reads the Vehicle Identification Number (VIN) within 30 seconds of starting and supports comprehensive OBD diagnostics, including engine RPM, speed, battery voltage, throttle position, coolant temperature, fuel consumption, and fault codes. With built-in low power protection, it automatically enters standby when voltage drops below 11V.
Advanced safety features include collision, vibration, low power, power cut, and speeding alarms, plus driving behavior monitoring for harsh acceleration or braking. The sleep and wake-up modes further optimize power efficiency, while SMS commands allow easy configuration of IP, APN, ports, and more.
Easy to install with plug-and-play functionality, the FETACA® tracker is ideal for fleet management, personal vehicle monitoring, and driver behavior analysis—delivering peace of mind and precise control.
